Vibro Screen

  • Model: DY800-1S
  • Equipment material: Carbon steel Q235
  • Valid Diameter of screen: 760 mm
  • Mesh size scope: 0-300 mesh
  • Motor Power: 0.55 kw
  • Warranty: 18 months
  • vibro screen
  • vibro screen
  • vibro screen
  • vibro screen
■ Video
■ Specifications
Features of Vibro Screen:
1.High screening efficiency, refined design, used for any powders and particles material.
2.Good sealing property, could reach national environmental standards.
3.Easy to operate, could continuous operations.
4.Unique screen frame design. Easy to replace new sieve, reduce staff’s maintenance time.
Application of Vibro Screen:
1.Chemical industry: resin, pigment, medicine, grease, paint, palette, etc. powders and particles.
2.Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc. powders and particles.
3.Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc. powders and particles.
4.Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc. powders and particles.
5.Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc. powders and particles.
6.Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc. powders and particles.
Certificates:
1.ISO International Standards ensure that products and services are safe, reliable and of good quality.
2.CE certification is designed to protect EU consumers by regulating products to reduce possible dangers to people and the environment.
■ Technical Data
Model

Valid Diameter of screen(mm)

Effective surface(㎡)

Layers

Power(kw)

DY-600-1

DY-600-2

DY-600-3

560

0.2375

1-3

0.25

0.55

0.55

DY-800-1

DY-800-2

DY-800-3

760

0.4416

1-3

0.55

0.75

0.75

DY-1000-1

DY-1000-2

DY-1000-3

930

0.6789

1-3

0.75

1.1

1.5

DY-1200-1

DY-1200-2

DY-1200-3

1130

1.0382

1-3

1.1

1.5

1.75

DY-1500-1

DY-1500-2

DY-1500-3

1430

1.6052

1-3

1.5

2.2

2.2

DY-1800-1

DY-1800-2

DY-1800-3

1730

2.3523

1-3

2.2

2.2

3.0
